0.75 inch round small white 128x128 dots OLED display GDOR0075W

Any questions, just feel free to contact me, my email is: clara@good-display.com

This is a white circular OLED display with small molecular organic light emitting diode, 0.75 inch with 128x128 pixels. The drive IC is SSD1327. Its operating temperature is -40℃~70℃, storage temperature is -40℃~85℃. The pixel luminance is 80(Typ) cd/m².
This OLED display possessing the excellent characteristics such as autoluminescence, wide angle of view, wide temperature range becomes the ideal choice for instruments and apparatus. Its circular design is also a good choice for other special application.


· Autoluminescence.
· Circular.
· Ultra low power consumption.
· Wide temperature range
· Come with helpful manual


1. 0.75 inch circular OLED display GDOR0075W * 1pc
2.Helpful manual(sent via email or download link) *1pc



Part Number	GDOR0075W
Diagonal Size	0.75 inch
Display Mode	Passive Matrix
Display Color	Monochrome (White)
Number of Pixels	128x128
Interface	Serial Peripheral Interface, I2C Interface
Driver IC	SSD1327
Outline Dimension	23.15 (W) x 40.93 (H) x 1.21 (T)  (mm)
Active Area	D=19.18 (mm)
Pixel Pitch	0.15 (W) x 0.15 (H)  (mm)
Pixel Size	0.13 (W) x 0.13 (H)  (mm)
Brightness(Typ)	80 cd/m²(Typ)
Operating Temperature	-40℃~70℃
Storage Temperature	-40℃~85℃
